Información técnica
| TENSION (VOLTAGE) | 12 [V] |
| CORRIENTE (CURRENT) | 50 [A] |
| TIPO DE ENTRADA (INPUT TYPE) | TRIFASICO |
| TECNOLOGIA (TECHNOLOGY) | SCR |
| TIPO DE SALIDA (OUTPUT TYPE) | CC |
| ALTO (HEIGHT) | 50 [mm] |
| ANCHO (WIDTH) | 107 [mm] |
| LARGO (LENGTH) | 112 [mm] |
| ENTRE CENTRO (PITCH) | 82 [mm] |
| CON SENSOR (WITH SENSOR) | NO |
Aplicaciones
| Marca | Modelo | Versión | Cilindrada | Año | Cod. OEM | Cód. Motor |
| Victory | - | 4012240 | - | |||
| Victory | - | 4012241 | - | |||
| Victory | - | 4012718 | - | |||
| Victory | - | 4011961 | - | |||
| Victory | Boardwalk | 1700 | de 2013 a 2015 | 4013395 | - | |
| Victory | Gunner | 1700 | de 2015 a 2017 | 4013395 | - | |
| Victory | Hammer | 1700 | de 2008 a 2017 | 4013395 | - | |
| Victory | High Ball | 1700 | de 2012 a 2017 | 4013395 | - | |
| Victory | Jackpot | 1700 | de 2008 a 2016 | 4013395 | - | |
| Victory | Judge | 1700 | de 2013 a 2017 | 4013395 | - | |
| Victory | Kingpin | 1700 | de 2008 a 2012 | 4013395 | - | |
| Victory | Vegas | 1700 | de 2008 a 2017 | 4013395 | - |
×
