Technical specifications
| # DIENTES (#GEAR TEETH) | 10 |
| # ESTRIAS (# SPLINES) | 10 |
| LARGO (L) | 38.5 [mm] |
| DIAMETRO PINION (DP) | 27.8 [mm] |
| DIAMETRO BUJE (DI) | 12.5 [mm] |
| DIAMETRO EXTERIOR (DE) | 49 [mm] |
| SENTIDO DE GIRO (ROTATION) | HORARIO (CW) |
| EQUIVALENTE ZEN | 1779 |
Uses
| Brand | Model | Version | Displacement | Year | OEM | Cód. Motor |
| Fiat | - | 51899848 | - | |||
| Fiat | - | 55193356 | - | |||
| Fiat | Bravo II | 1.4 | - | |||
| Fiat | Doblo | 1.4 | - | |||
| Fiat | Grand Punto | 1.4 | - | |||
| Fiat | Grand Siena | 1.4 | - | |||
| Fiat | Idea | 1.2 | - | |||
| Fiat | Palio | 1.4 | - | |||
| Fiat | Panda | 1.1 1.2 y 1.4 | - | |||
| Fiat | Punto | 1.4 | - | |||
| Fiat | Strada | - | ||||
| Hitachi | - | S114907 | - | |||
| Hitachi | - | S114905 | - | |||
| Hitachi | - | S114906 | - | |||
| Hitachi | - | S114951A | - | |||
| Hitachi | - | S114951B | - | |||
| Lancia | Musa | 1.4 | - | |||
| Lancia | Ypsilon | 1.4 | - | |||
| Lester | - | 33114 | - | |||
| Lester | - | 32726 | - | |||
| Reemplazo | ZEN | 1779 | - |
×
